Canon’s EOS 5DS R is the highest-resolution full-frame camera yet made. Andy Westlake investigates

Product Overview

Overall rating:

Canon EOS 5DS R

Features:
Build/Handling:
Metering:
Autofocus:
AWB Colour:
Dynamic Range:
LCD viewfinder:

Pros:

  • + Extraordinary image quality with huge levels of detail
  • + Highly refined control layout and user interface
  • + Excellent, extremely accurate autofocus system
  • + Rugged, professional-level construction

Cons:

  • - Fixed rear screen is inconvenient for tripod work
  • - Relatively limited ISO range
  • - Huge file sizes

Product:

Canon EOS 5DS R review

Manufacturer:

Price as reviewed:

£3,200.00 (body only)

Latest deal

Loading
TAGS:

ISO sensitivity and Noise

At low ISOs, the EOS 5DS R delivers exceptional levels of detail with essentially no visible noise. It’s only at ISO 800 that some noise starts to creep in when looking at the image on the pixel level, but you’d have to make huge prints for it to be visible. Noise only really starts to have any sort of negative impact at ISO 3200, mainly causing a slight deterioration of shadow detail. But with a fine granular pattern it’s not hugely problematic, and easily dealt with in post processing, although at the usual expense of fine detail and colour saturation. Crucially, there’s little unsightly low frequency chroma noise, which tends to be difficult to remove. The top two ISO settings are both perfectly usable, suggesting Canon could have offered a wider sensitivity range from this sensor.

ISO noise – JPEG

Below are 100% crops from JPEG files at a full set of ISO settings, shot using the EF 100mm f/2.8 Macro USM at f/13.

Canon EOS 5DS R noise, JPEG ISO 50

Canon EOS 5DS R noise, JPEG ISO 50

Canon EOS 5DS R noise, JPEG ISO 100

Canon EOS 5DS R noise, JPEG ISO 100

Canon EOS 5DS R noise, JPEG ISO 200

Canon EOS 5DS R noise, JPEG ISO 200

Canon EOS 5DS R noise, JPEG ISO 400

Canon EOS 5DS R noise, JPEG ISO 400

Canon EOS 5DS R noise, JPEG ISO 800

Canon EOS 5DS R noise, JPEG ISO 800

Canon EOS 5DS R noise, JPEG ISO 1600

Canon EOS 5DS R noise, JPEG ISO 1600

Canon EOS 5DS R noise, JPEG ISO 3200

Canon EOS 5DS R noise, JPEG ISO 3200

Canon EOS 5DS R noise, JPEG ISO 6400

Canon EOS 5DS R noise, JPEG ISO 6400

Canon EOS 5DS R noise, JPEG ISO 12800

Canon EOS 5DS R noise, JPEG ISO 12800

 ISO Noise – Raw

Below are the same crops, but now taken from the corresponding raw files converted using Adobe Camera Raw with noise reduction turned off. The idea here is to give an impression of the underlying noise on the files; normally you’d use noise reduction to minimise its appearance. Again we see very clean images at ISO 50, with some noise starting to become clearly visible around ISO 800, but only having a clearly negative effect at the top two settings.

Canon EOS 5DS R noise, raw ISO 50

Canon EOS 5DS R noise, raw ISO 50

Canon EOS 5DS R noise, raw ISO 100

Canon EOS 5DS R noise, raw ISO 100

Canon EOS 5DS R noise, raw ISO 200

Canon EOS 5DS R noise, raw ISO 200

Canon EOS 5DS R noise, raw ISO 400

Canon EOS 5DS R noise, raw ISO 400

Canon EOS 5DS R noise, raw ISO 800

Canon EOS 5DS R noise, raw ISO 800

Canon EOS 5DS R noise, raw ISO 1600

Canon EOS 5DS R noise, raw ISO 1600

Canon EOS 5DS R noise, raw ISO 3200

Canon EOS 5DS R noise, raw ISO 3200

Canon EOS 5DS R noise, raw ISO 6400

Canon EOS 5DS R noise, raw ISO 6400

Canon EOS 5DS R noise, raw ISO 12800

Canon EOS 5DS R noise, raw ISO 12800



  1. 1. Canon EOS 5DS R review: Introduction
  2. 2. Features
  3. 3. Screen and viewfinder
  4. 4. Build and handling
  5. 5. Focusing
  6. 6. Performance
  7. 7. Image quality
  8. 8. ISO sensitivity and Noise
  9. 9. Canon EOS 5DS R compared to 5DS
  10. 10. Conclusion
  11. 11. Page 11
Page 8 of 11 - Show Full List
